ASUS TUF Gaming GT501 Mid-Tower Case (Gray)
ASUS GT501 Specs
Compatibility
| Motherboard Support | ATX, E-ATX, Micro-ATX, Mini-ITX |
| External Drive Bays | None |
| Internal Drive Bays | 4 x 2.5/3.5" 3 x 2.5" |
| Expansion Slots | 7 x Full Height + 2 |
| Maximum GPU Length | 16.54" / 420 mm |
| CPU Cooler Height | 7.09" / 180 mm |
| Supported PSU Size | ATX |
| Maximum PSU Length | 9.45" / 240 mm |
Cooling
| Fan Mounting (Front) | 3 x 120 mm Or 2 x 140 mm |
| Fan Mounting (Rear) | 1 x 120 mm Or 1 x 140 mm |
| Fan Mounting (Side) | None |
| Fan Mounting (Top) | 3 x 120 mm Or 2 x 140 mm |
| Fan Mounting (Bottom) | None |
| Fans Included (Front) | 3 x 120 mm LED (1200 rpm) |
| Fans Included (Rear) | 1 x 140 mm (Variable rpm) |
| Maximum Radiator Size (Front) | 360 mm |
| Maximum Radiator Size (Rear) | 140 mm |
| Maximum Radiator Size (Top) | 360 mm |
| Fan Mounting (Internal) | None |
| Fans Included (Internal) | None |
| Fan Controller Included | No |
| Filter Locations | Bottom, Front, Top |
I/O
| Connections | 2 x USB Type-A (USB 3.1 / USB 3.2 Gen 1) |
| Media Card Slots | None |
| Audio Connections | 1 x 3.5 mm Input 1 x 3.5 mm Output |
| Display Connections | None |
Physical
| Windowed Panel | Yes |
| Material | Tempered Glass, Steel |
| Built-In Lighting | No |
| Cable Management Space | 1.18" / 30 mm |
| Dimensions (W x H x D) | 9.88 x 21.73 x 21.46" / 251 x 552 x 545 mm |
| Weight | 23.15 lb / 10.5 kg |
| Warranty Length | Limited 2-Year Warranty |
Packaging Info
| Package Weight | 28.32 lb |
| Box Dimensions (LxWxH) | 25.4 x 24.9 x 13.2" |
