ASUS PB60V (Intel® Core™ i7-8700T)
|
Model and Spec Summary |
PB60V (Core-i7 8th Gen/ 8GB/ 512GB M.2 SSD/ Wired KBMS/ VESA/ 802.11ac/ Win10 PRO/ ASUS Control Center/ DisplayPort) |
|
| Model Name | PB60V-B7098ZD | |
| Part # | 90MS01N1-M00990 | |
| CPU Generation & Platform | 8th Gen (Coffee Lake) | |
| CPU | Intel® Core™ i7-8700T (12M, 6 Core, 2.40GHz up to 4.00GHz) |
|
| Chipset |
Intel® Q370 supports Intel vPRO™ and Unite™ |
|
| Memory |
8GB DDR4 2400MHz SO-DIMM (4GB x 2pcs) (4GB up to 32GB) |
|
| SO-DIMM Slot | 2 x SO-DIMM slots | |
|
Storage
|
512GB M.2 2280 SSD (PCIe) *supports NVMe SSD and Intel® Optane™ memory |
|
|
Supports up to 1 x 2.5" HDD (up to 1TB) + 1 x M.2 2280 SSD PCIe G3X4/ SATA (up to 256GB)* *Optional storage must confirmed SKU before configuring |
||
| Graphics | Integrated-Intel® UHD Graphics (optional Nvidia® GeForce® GTX1650 or Nvidia® Quadro® P620/ P1000 Graphics Module) |
|
|
Networking
|
LAN | Intel® 10/100/1000 Mbps |
| Wireless | Intel® 9560 vPro 802.11ac, 2x2 Bluetooth V5.0 |
|
|
Audio
|
Codec | REALTEK® ALC3236 Codec, 2 Channel |
| Internal Speaker | OPTIONAL (1W speaker) |
|
| VESA Mounting Kit | YES | |
| Card Reader | N/A | |
|
Interface
(I/O Ports) |
Front |
1 x USB 3.1 Gen1 Type-C 4 x USB 3.1 Gen2 Type-A (1 x Quick Charge) 1 x Audio Jack 1 x Mic in Jack |
| Side | N/A | |
| Rear |
1 x USB 3.1 Gen2 Type-A 2 x USB 2.0 1 x HDMI 2.0 1 x DisplayPort 1.2 1 x DisplayPort 1.2 (COM/VGA port option)* 1 x RJ45 LAN Port 1 x External WiFi Antenna Port 1 x Kensington slot 1 x DC-in *default DisplayPort; optional ports must be confirmed before configuring |
|
| Support Ultra HD 4K | YES | |
| Dual or Multiple LCD Support |
up to 3 LCD Support (up to 7 LCD with Graphics Module) *refer to OUTPUT RESOLUTION sheet for display configuration options |
|
| ODD | OPTIONAL (CTO from factory) |
|
| COM Port | OPTIONAL (CTO from factory) |
|
| TPM Onboard | TPM 2.0 | |
| Color | Black | |
| OS | Win 10 PRO M12 | |
| Dimensions (WxDxH) | 175 x 175 x 34.2 mm (1.05L) | |
| Power Supply | 90W Power Supply | |
|
Peripherals & Accessories
|
Wired Keyboard + Mouse | |
|
1 x VESA Mount Kit 1 x Stand 1 x AC Adapter + Power Cord 1 x Quick Start Guide w/ ACC Activation Key 1 x Warranty Card 1 x Quick Start Guide |
||
| Warranty | 3-years, carry-in | |
